9 Cores Waterproof Fiber Distribution Box

This type of fiber access termination box(FDB) is able to hold up to 9 subscribers. It is used as a termination point for the feeder cable to connect with the drop cable in the FTTx network system. It integrates fiber splicing, splitting, distribution, storage, and cable connection in one solid protection box.

Model:CFO-FDB-73
MOQ:3>500
Place of Origin:3China
Brand:3CFO
Material:ABS
Delivery Time:35-15days
Start Port:shenzhen
Supply Ability:500pcs/day
  • Description
  • Make an inquiry
    Configuration



    Products Features


    Pre-Connected 10 Prot Fiber Optic Distribution Box For FTTH FTTB FTTC FTTA

    1.   Apply to wall-mounted Hold-up and pole-type installation
    2.   High-strength material with good weather adaptability and UV resistance.
    3.   Port into the end and leakage design, no need to open the box, easy construction.
    4.   Internal multi-wiring, can be independent or combined with different types of PLC Splitter.
    5.   Corning、Huawei and conventional waterproof adapters can be installed, And these adapters can be distinguished by different colors
    6.   Ultrasonic welding, excellent sealing performance, Waterproof to IP68.

    The bottom shell and upper cover are welded by hot plate welding, which is not detachable...Pre-connected technology Plug and play.Moisture-proof, waterproof, dust-proof, anti-aging.Protection level up to IP68.
